Marzouk Steel, located in Tunis, Tunisia, stands out as a top manufacturer and supplier of high-quality carbon steel products, particularly known for their EN 10084 Grade 16MnCr5 pipe range. With a strong dedication to excellence and precision, Marzouk Steel guarantees that every pipe adheres to strict international standards for durability and performance. Catering to a wide array of industries, the company merges cutting-edge production methods with rigorous quality control, delivering dependable solutions for both local and global markets. Their deep expertise in steel processing makes them a reliable partner for clients in search of premium-grade 16MnCr5 carbon steel piping.
Carbon Steel EN 10084 Grade 16MnCr5 Pipe is an alloy steel with a content of about 0.14-0.19% carbon, 1.0-1.3% manganese, and 0.8-1.1% chromium and possesses good hardenability and wear resistance. Its mechanical characteristics are tensile strength of 600-800 MPa, yield strength about 400 MPa, and good ductility with elongation of 8-12%. It is suited for carburizing processes to obtain a hard, wear-resistant surface with a tough core. The benefits are outstanding machinability, superior durability, and applicability to uses such as auto parts and gears demanding strength and wear resistance.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| Bs EN 10084 Grade C10R Welded Pipe Size | 5.0 mm – 1219.2 mm |
| DIN En 10084 C16e Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| DIN EN 10084 Grade C16E EFW Pipe size | 5.0 mm – 1219.2 mm |
| Norme En 10084 C15e Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| EN 10084 Grade 16MnCr5 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| EN 10084 Grade C16R Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Norme En 10084 C15e Welded Tube Size | 6.35 mm OD To 152 mm OD |
| En 10084 Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| En 10084 C10e Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN En 10084 C16e Marking | All EN 10084 Material are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Uni En Iso 10084 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Manufacturers of EN 10084 Grade C16E Pipe |
|
| EN 10084 Grade C16R Carbon Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| EN 10084 Grade 16MnCr5 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Bs EN 10084 Grade C10R Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| EN 10084 Grade C16E Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| DIN En 10084 C15e – 1.1141 End | Plain End, Beveled End, Treaded Pipe & Tube |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Heat Treatment Charts, EN 10084 Grade 16MnCr5 Pipe HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| EN 10084 Grade C10R Carbon Steel Specialize in |
|
| DIN EN 10084 Grade C16E Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Chemical Properties | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.14-0.19 | max 0.40 | 1.00-1.30 | 0.035 | 0.035 | – | – | 0.80-1.10 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
EN 10084 Grade 16MnCr5 is a low-alloy case-hardening steel that boasts a well-balanced composition of 0.14–0.19% carbon, 1.00–1.30% manganese, 0.15–0.35% chromium, along with trace elements of silicon, sulfur, and phosphorus. This unique chemical makeup offers remarkable hardenability, strength, and wear resistance. On the mechanical side, 16MnCr5 showcases a tensile strength ranging from 500 to 700 MPa and a yield strength of 330 MPa, with a commendable elongation of 12–15%. Its blend of toughness and ductility makes it perfect for carburizing, quenching, and tempering processes, ensuring long-lasting performance in demanding engineering applications where both surface hardness and core toughness are essential.
16MnCr5 pipes find extensive use in the automotive, machinery, and engineering sectors, thanks to their outstanding wear resistance and mechanical strength. They are particularly suited for crafting gears, shafts, pinions, axles, and other components that need a hard exterior and a resilient core. Moreover, these pipes are utilized in heavy machinery, transport equipment, and industrial tools, where durability under stress and impact is crucial. The combination of machinability, carburizability, and reliability makes EN 10084 Grade 16MnCr5 pipes a favored option for precision engineering and structural applications in both commercial and industrial environments.
