Marzouk Steel, located in Tunis, Tunisia, has earned a solid reputation as a reliable manufacturer and supplier of ASME SA 387 Grade 9 Class 1 and Class 2 sheets and plates. The company is dedicated to crafting top-notch alloy steel products that meet the rigorous ASME standards for pressure vessel applications. With state-of-the-art manufacturing facilities and a strong focus on quality assurance, Marzouk Steel provides materials that are recognized for their dependability, precise dimensions, and consistent performance. Their deep technical knowledge and customer-centric approach make them a trustworthy source for SA 387 Grade 9 plates, catering to both local and international markets.
ASME SA 387 Grade 9 Class 1 & 2 Sheets and Plates are chromium-molybdenum alloy plates suitable for applications under high pressure and temperature. They contain around 9% Chromium and 1% Molybdenum. Ensuring maximum oxidation and corrosion resistance together with excellent strength. They are famous for their durability and thermal stability and find wide applications in extreme environments requiring extraordinary performance under rigorous conditions.
| Standard | ASTM A387 / ASME SA387 |
|---|---|
| Width | 1000mm-3000mm |
| Thickness | 1.0mm – 200mm |
| Production | Hot-Rolled (HR) / Cold-Rolled (CR) |
| Grade | C | Si | Mn | P | S | Cr | Mo |
| A387 GR.9 CL.2 | 0.15 max | 2.05 max | 0.25-0.66 max | 0.030 max | 0.030 max | 7.90-10.10 max | 0.85-2.10 max |
| Grade | A387 GR.9 CL.2 | |||
| A387 GR.9 CL.2 | Thickness mm | Yield Min Mpa | Tensile Mpa | Elongation Min % |
| t≦50 | 310 | 515-690 | 18 | |
| 50<t≦200 | – | – | – | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
ASME SA 387 Grade 9 is a chromium-molybdenum alloy steel that contains around 8.00–10.00% chromium and 0.90–1.10% molybdenum, along with carefully controlled amounts of carbon, manganese, silicon, sulfur, and phosphorus. This specific composition gives it remarkable resistance to high-temperature oxidation and creep. Class 1 plates are provided in a normalized state, while Class 2 plates undergo quenching and tempering to achieve greater strength. In terms of mechanical properties, these plates boast high tensile and yield strength, good toughness, and outstanding resistance to pressure at elevated temperatures.
ASME SA 387 Grade 9 Class 1 and Class 2 sheets and plates find extensive use in pressure vessels, boilers, and heat exchangers that operate under high temperatures. They are commonly utilized in petrochemical plants, refineries, power generation facilities, and chemical processing industries. These plates are ideal for equipment that faces high pressure, thermal stress, and corrosive environments. Thanks to their exceptional creep resistance, strength, and long-term stability, SA 387 Grade 9 materials are the go-to choice for critical high-temperature and high-pressure industrial applications.
