Marzouk Steel, headquartered in Tunis, Tunisia, is a trusted manufacturer and supplier of high-quality steel products for pipeline and industrial applications. Among its dependable offerings are Carbon Steel F48 Forged Fittings, designed for piping systems that require reliable strength and secure connections under moderate pressure conditions. Manufactured in accordance with ASTM A694 standards, these forged fittings are engineered to match API 5L X48 pipeline grades. With strict quality control, precision forging, and adherence to international specifications, Marzouk Steel delivers F48 forged fittings that ensure durability, safety, and long-term service performance.
Carbon Steel F48 Forged Fittings are produced from high-quality carbon steel with controlled chemical composition. This grade provides good yield and tensile strength, reliable toughness, and resistance to mechanical stress. The forging process enhances grain structure and strength, while heat treatment ensures uniform mechanical properties, good weldability, and dimensional accuracy. These fittings are designed to perform consistently in moderate-pressure and temperature applications.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F48 | 0.06-0.10 | 0.20-0.40 | 1.10-1.40 | ≤ 0.020 | ≤ 0.010 | 1.20-1.70 | 0.20-0.40 | ≤ 0.30 | ≤ 0.25 | 0.02-0.06 | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| F48 | 70 | 82 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F48 Forged Screwed Elbows, Street Elbow, Carbon Steel F48 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F48 Reducing Coupling, Carbon Steel F48 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F48 Threaded Bushing, Carbon Steel F48 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F48 Barrel Nipples, CS F48 Forged Threaded Boss, Carbon Steel F48 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F48 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F48 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F48 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F48 Coupling |
Carbon Steel F48 Forged Fittings are widely used in oil and gas pipelines, water transmission systems, and general industrial piping. Common applications include elbows, tees, couplings, unions, and threaded fittings where secure, leak-resistant connections are required. These fittings are suitable for onshore pipeline projects, refineries, petrochemical plants, and infrastructure developments. Engineers and contractors rely on F48 forged fittings for their reliability, compliance, and cost-effective performance in medium-duty piping systems.
Marzouk Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Tunis, Tunisia.
