Marzouk Steel is a top industrial steel product manufacturer and supplier in Tunis, Tunisia. With an impeccable reputation for quality, Marzouk Steel provides a vast array of superior products, such as Carbon Steel F52 Forged Fittings. The fittings are renowned for their superior strength, durability, and resistance to extreme conditions and, therefore, are suited to rigorous applications in industries like oil and gas, petrochemical, and construction. Dedicated to quality, Marzouk Steel guarantees every product is of the highest quality, delivering dependable solutions to meet all your piping requirements.
Carbon Steel F52 Forged Fittings are made of a low-alloy steel with a specific percentage of carbon, manganese, silicon, phosphorus, sulfur, and small amounts of other elements. The typical composition is approximately 0.22% carbon, 1.60% manganese, and 0.30% silicon, offering a compromise between strength and ductility. These fittings have good mechanical properties with tensile strength of 560 MPa (min), yield strength of 355 MPa (min), and elongation of 22% (min) in 50 mm. These properties in combination provide great performance and reliability under high-temperature and high-pressure conditions.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F52 | 0.16-0.22 | 0.15-0.40 | 1.10-1.40 | ≤ 0.025 | ≤ 0.012 | 0.20-0.35 | ≤ 0.50 | ≤ 0.30 | ≤ 0.25 | – | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 52 | 66 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F52 Forged Screwed Elbows, Street Elbow, Carbon Steel F52 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F52 Reducing Coupling, Carbon Steel F52 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F52 Threaded Bushing, Carbon Steel F52 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F52 Barrel Nipples, CS F52 Forged Threaded Boss, Carbon Steel F52 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F52 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F52 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F52 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F52 Coupling |
Carbon Steel F52 Forged Fittings are extensively utilized across different industries because of their high strength, durability, and resistance to high pressure and temperature. They are used in the oil and gas, petrochemical, power generation, and construction industries, where a safe piping system is required. The fittings are ideal for connecting pipes, valves, and other equipment in high-stress operations. They are used in severe applications such as offshore drilling, power generation, chemical processing, and hydraulic systems. Carbon Steel F52 Forged Fittings ensure smooth fluid flow and structural integrity, even in harsh conditions, and thus are an option for demanding operations.
