Marzouk Steel, located in Tunis, Tunisia, has built a solid reputation as a reliable manufacturer and supplier of carbon steel F80 forged fittings, catering to the oil, gas, petrochemical, and industrial sectors. With state-of-the-art forging facilities and a commitment to rigorous quality control, Marzouk Steel guarantees that every fitting is crafted with high precision, strength, and reliability. The company prides itself on offering tailored solutions, prompt delivery, and expert technical support. Their F80 forged fittings are engineered to endure high pressure and temperature conditions, ensuring long-lasting durability, leak-proof connections, and exceptional mechanical performance for critical piping and industrial applications.
Carbon Steel F80 Forged Fittings consist of mainly carbon (0.30-0.60%), traces of manganese, phosphorus, sulfur, and silicon, with the aim of having a balance between strength and flexibility. The mechanical properties consist of high tensile strength, which is normally in the range of 485 to 620 MPa, and yield strength in the range of 250 to 400 MPa. They also possess good impact toughness and hardness, which is normally between 160 to 190 HB. Their corrosion and pressure resistance makes them perfect for aggressive industrial applications with guaranteed long performance and durability across different systems.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F80 | 0.17-0.23 | 0.15-0.40 | 1.30-1.60 | ≤ 0.025 | ≤ 0.015 | 0.45-0.65 | ≤ 0.30 | ≤ 0.30 | ≤ 0.25 | – | 0.025~0.050 |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 65 | 77 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F80 Forged Screwed Elbows, Street Elbow, Carbon Steel F80 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F80 Reducing Coupling, Carbon Steel F80 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F80 Threaded Bushing, Carbon Steel F65 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F80 Barrel Nipples, CS F80 Forged Threaded Boss, Carbon Steel F80 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F80 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F80 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F80 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F80 Coupling |
F80 forged fittings find extensive use in pipelines and systems across the oil, gas, chemical, and power industries. Common applications include elbows, tees, reducers, couplings, and flanges within high-pressure and high-temperature piping networks. They are also essential in refinery systems, chemical processing plants, and industrial machinery where mechanical strength, reliability, and leak-proof performance are paramount. Thanks to their sturdy construction, precise dimensions, and outstanding mechanical properties, F80 forged fittings ensure safe, efficient, and long-lasting operation in demanding projects within the industrial and energy sectors.
