Marzouk Steel is a reliable Tunisia-based manufacturer and supplier of high-quality forged fittings for industrial use. Committed to excellence, we offer an extensive variety of products, including Carbon Steel F65 Forged Fittings, renowned for their high strength, long lifespan, and resistance to extreme pressure and heat. Our fittings are designed to the highest industry standards, providing reliability and performance in extreme conditions. At Marzouk Steel, we take pride in providing precision-engineered solutions to address the varied requirements of our international customers.
Carbon Steel F65 Forged Fittings are manufactured from a high-strength alloy of carbon steel, providing high wear and corrosion resistance. The general composition is carbon (0.60-0.70%), manganese (0.90-1.20%), phosphorus (max 0.035%), sulfur (max 0.035%), and silicon (0.15-0.40%), with the balance being iron. The fittings exhibit excellent mechanical properties, with a tensile strength of at least 650 MPa (95,000 psi) and a yield strength of at least 450 MPa (65,000 psi). They also exhibit good toughness and ductility and can be used in high-temperature, high-pressure industry applications like in the oil and gas industry.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F65 | 0.17-0.23 | 0.15-0.40 | 1.30-1.60 | ≤ 0.025 | ≤ 0.015 | 0.45-0.65 | ≤ 0.30 | ≤ 0.30 | ≤ 0.25 | – | 0.025~0.050 |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 65 | 77 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F65 Forged Screwed Elbows, Street Elbow, Carbon Steel F65 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F65 Reducing Coupling, Carbon Steel F65 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F65 Threaded Bushing, Carbon Steel F65 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F65 Barrel Nipples, CS F65 Forged Threaded Boss, Carbon Steel F65 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F65 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F65 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F65 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F65 Coupling |
Carbon Steel F65 Forged Fittings find extensive applications in high-temperature, high-pressure conditions owing to their superior strength and durability. Fittings are suited for usage in oil and gas, petrochemical, power generation, and construction industries. They are traditionally applied in pipelines, valves, pumps, and heat exchangers, where corrosion resistance and capability to endure extreme conditions are paramount. Their excellent mechanical properties qualify them for systems requiring tight seals, leak-free operation, and consistent connections. Carbon Steel F65 Forged Fittings also find application in hydraulic systems and structural use, providing long-term performance.
